High-Speed Product Test Controllers

The Scout products are high-performance Serial Bus controllers designed specifically for high-speed automated test and characterization applications. Unlike traditional USB to GPIO dongles, Scout products are architected around an FPGA core to minimize execution time and provide deterministic timing.



The SC4415 can be configured for support of MIPI-RFFE V2.1 and/or MIPI-I3C (including legacy I2C).



This device supports manual control using a terminal emulator or software control via it’s API for integration into Automated Test Environments (ATEs). The interface is compatible with any software that supports communication via COM port. The device is verified on Windows, Linux, and iOS systems.

MIPI-RFFE

The MIPI RF Front-End interface (MIPI-RFFE), is a dedicated control interface for the RF front end of a device. It enhances the control of the complex device environment, which has rigorous performance requirements, and can include 10 to 20 components such as power amplifiers, antenna tuners, filters, and switches. The interface can be applied to the full range of RF front-end components to simplify product design, configuration, and integration, and to facilitate interoperability of components supplied by different vendors. The conveniences make it easier for manufacturers to address end-user needs for faster data speeds and better call quality, develop scalable solutions, and expedite time to market for new designs in the mobile, automotive and IoT sectors.

MIPI-I3C

MIPI-I3C is a bus interface for connecting sensors to an application processor. It is a core sensor integration technology that can combine multiple sensors from different vendors in a device to streamline integration and provide cost efficiencies. It gives developers unprecedented opportunity to craft innovative designs for any mobile product, from smartphones, to wearables, to automobile safety systems.

Serial Bus Controllers

SC4410-200x200

SC4410 - MIPI-RFFE Bus Controller

The USB Scout is a fast and flexible USB to serial and general purpose I/O (GPIO) adaptor for control applications. It provides the user with a configurable bridge between USB and 8 programmable IOs. More…

SC4415-200x200

SC4415 - Serial Bus Controller (MIPI-I3C, MIPI-RFFE, and SPI)

The Scout SC4415 is the next-generation model in the Scout product line. It incorporates enhanced features as well as support for the emerging MIPI-I3C protocol. More…
