Model SC2426
26 GHz Frequency Converter
The module is designed to interface directly with software-defined radios, such as those commonly implemented using Analog Device’s Mixed-Signal Front-End (MxFE), National Instruments USRP, or similar Software Defined Radio.
Up to four modules can be combined in parallel to create complex MIMO applications.
Typical Applications
- 5G FR3 Research and Development
- Aerospace and Defense Application Prototyping
- Software Defined Radio Applications
- Advanced Wireless Communications Research
Control of the module is provided via the USB, UART, or SPI interfaces. Most users will find it convenient to control the module using the console interface over USB. Alternatively, embedded controllers may access the UART or SPI interfaces available on the external Control Ports.
Two API protocols are available. The first is ASCII-based, and its commands follow the SCPI structure as defined in IEEE 488.2. The second is a binary protocol, targeted at embedded control applications where speed and timing are critical. Both protocols are detailed in an API Specification.
Up to 4 units can be combined in a vertical stack to create a complex 4 x 4 MIMO radio system. In this scenario, the internal control buses are routed to the cascaded modules over the Expansion Port. In this manner, API commands sent on the primary unit, can be redirected to the downstream modules. This eliminates the need for multiple controllers and simplifies timing and synchronization between units. Module addresses are set using a DIP switch on the Configuration Port.
Secondary and External Control Ports are also available. These ports expose Power, SPI, I2C, UART and GPIO that provide users with a convenient method of interfacing to external front-end modules, such as integrated antenna arrays or switched filter banks.
Block Diagram
